NON-DRILL Post & Handrail System

NON-DRILL
Products » Edge Protection / Containment » NON-DRILL

NON-DRILL Post & Handrail System

NON-DRILL
  • Eliminate the need for drilling with the NON-DRILL edge protection post & handrail system
  • Connect to lifting anchors on precast structures
  • NON-DRILL works seamlessly with 1.3, 2.5, 5, 10T connections and hairpin anchors
  • By connecting to the anchor – eliminate human error and meet industry standards for edge protection
  • With NON-DRILL you avoid – costly labour hire, drilling into concrete – exposing steel, cutting off bolts

Designed to meet the following standards:

  • BS EN 1991 – 1: Actions on Structures
  • BS EN ISO 14122 – Safety of Machinery – Permanent means of access to machinery (covering fixed platforms, walkways, stairways, and ladders)
    • Under 350N/m or Catergory 1 lateral loading
    • Under 750 N/m or Category 2 lateral loading (using the same connection, with increased post thickness)
  • Eliminate the need for drilling with the NON-DRILL edge protection post & handrail system
  • Connect to lifting anchors on precast structures
  • NON-DRILL works seamlessly with 1.3, 2.5, 5, 10T connections and hairpin anchors
  • By connecting to the anchor - eliminate human error and meet industry standards for edge protection
  • With NON-DRILL you avoid - costly labour hire, drilling into concrete - exposing steel, cutting off bolts
  • Designed and patented, meets the following standards:
    • BS EN 1991-1: Actions on structures
    • BS EN ISO 14122 - Safety of Machinery - Permanent means of access to machinery (covering fixed platforms, walkways, stairways, and ladders)
      • Under 350N/m or Catergory 1 lateral loading
      • Under 750 N/m or Category 2 lateral loading (using the same connection, with increased post thickness)
Get a quote
SKU: 230121
NON-DRILL Post – 1.060m
  • Meets and passes all load requirements per BS EN 13374:2013
  • Complies with BS EN 1991-1: Structural design actions, Part 1: Permanent, imposed, and other actions, and BS 5395-3:1985: Code of practice for stairs, ladders, and walkways: Under 350 N/m, or "Category 1" lateral loading and under 750 N/m, or "Category 2" lateral loading (using the same connection, increasing the post thickness)


Add
SKU: 230122
NON-DRILL 2.5T Clutch
  • Meets and passes all load requirements per BS EN 13374:2013
  • Complies with BS EN 1991-1: Structural design actions, Part 1: Permanent, imposed, and other actions, and BS 5395-3:1985: Code of practice for stairs, ladders, and walkways: Under 350 N/m, or "Category 1" lateral loading and under 750 N/m, or "Category 2" lateral loading (using the same connection, increasing the post thickness)


Add
SKU: 230123
NON-DRILL 5.0T Clutch
  • Meets and passes all load requirements per AS/NZS 4994
  • Complies to AS/NZS 1170.1 Structural design actions, Part 1: Permanent, imposed and other actions, AS 1657:2018 Fixed platforms, walkways, stairways & ladders: • under 350N/m, or “Category 1” lateral loading • under 750N/m, or “Category 2” lateral loading (using the same connection, increasing the post thickness


Add
SKU: 230124
NON-DRILL 10.0T Clutch and extra baseplate
  • Meets and passes all load requirements per BS EN 13374:2013
  • Complies with BS EN 1991-1: Structural design actions, Part 1: Permanent, imposed, and other actions, and BS 5395-3:1985: Code of practice for stairs, ladders, and walkways: Under 350 N/m, or "Category 1" lateral loading and under 750 N/m, or "Category 2" lateral loading (using the same connection, increasing the post thickness)


Add
SKU: 230120
NONDRILL Post AdaptaPanel Bracket
Non-Drill Post AdaptaPanel Bracket


Add
SKU: 230128
NON-DRILL Modified Clutch for 16mm Ferrule / Drop In
  • Meets and passes all load requirements per BS EN 13374:2013
  • Complies with BS EN 1991-1: Structural design actions, Part 1: Permanent, imposed, and other actions, and BS 5395-3:1985: Code of practice for stairs, ladders, and walkways: Under 350 N/m, or "Category 1" lateral loading and under 750 N/m, or "Category 2" lateral loading (using the same connection, increasing the post thickness)


Add
SKU: 230129
NON-DRILL Modified Clutch for 20mm Ferrule / Drop In
  • Meets and passes all load requirements per BS EN 13374:2013
  • Complies with BS EN 1991-1: Structural design actions, Part 1: Permanent, imposed, and other actions, and BS 5395-3:1985: Code of practice for stairs, ladders, and walkways: Under 350 N/m, or "Category 1" lateral loading and under 750 N/m, or "Category 2" lateral loading (using the same connection, increasing the post thickness)


Add
SKU: 230126
NON-DRILL Modified Clutch for EdgePro/Hairpin Lifter - Type 1 To Suit; Ancon 8.5t (Purple) REID 7t Jaws (Orange) REID 8.5t 3DX (Yellow)
  • Meets and passes all load requirements per BS EN 13374:2013
  • Complies with BS EN 1991-1: Structural design actions, Part 1: Permanent, imposed, and other actions, and BS 5395-3:1985: Code of practice for stairs, ladders, and walkways: Under 350 N/m, or "Category 1" lateral loading and under 750 N/m, or "Category 2" lateral loading (using the same connection, increasing the post thickness)


Add
SKU: 230125
NON-DRILL Modified Clutch for EdgePro/Hairpin Lifter - Type 2 To Suit Ancon 4t (Red)
  • Meets and passes all load requirements per BS EN 13374:2013
  • Complies with BS EN 1991-1: Structural design actions, Part 1: Permanent, imposed, and other actions, and BS 5395-3:1985: Code of practice for stairs, ladders, and walkways: Under 350 N/m, or "Category 1" lateral loading and under 750 N/m, or "Category 2" lateral loading (using the same connection, increasing the post thickness)


Add
SKU: 230127
NON-DRILL Modified Clutch for EdgePro/Hairpin Lifter - Type 3 To Suit; Ancon 15t (Green) REID 10t Jaws (Blue)
  • Meets and passes all load requirements per BS EN 13374:2013
  • Complies with BS EN 1991-1: Structural design actions, Part 1: Permanent, imposed, and other actions, and BS 5395-3:1985: Code of practice for stairs, ladders, and walkways: Under 350 N/m, or "Category 1" lateral loading and under 750 N/m, or "Category 2" lateral loading (using the same connection, increasing the post thickness)


Add
SKU: 230130
NONDRILL Shear Stud Connection
  • Meets and passes all load requirements per BS EN 13374:2013
  • Complies with BS EN 1991-1: Structural design actions, Part 1: Permanent, imposed, and other actions, and BS 5395-3:1985: Code of practice for stairs, ladders, and walkways: Under 350 N/m, or "Category 1" lateral loading and under 750 N/m, or "Category 2" lateral loading (using the same connection, increasing the post thickness)


Add
My Quotes

Product Description

  • Eliminate the need for drilling with the NON-DRILL edge protection post & handrail system
  • Connect to lifting anchors on precast structures
  • NON-DRILL works seamlessly with 1.3, 2.5, 5, 10T connections and hairpin anchors
  • By connecting to the anchor – eliminate human error and meet industry standards for edge protection
  • With NON-DRILL you avoid – costly labour hire, drilling into concrete – exposing steel, cutting off bolts

Designed to meet the following standards:

  • BS EN 1991 – 1: Actions on Structures
  • BS EN ISO 14122 – Safety of Machinery – Permanent means of access to machinery (covering fixed platforms, walkways, stairways, and ladders)
    • Under 350N/m or Catergory 1 lateral loading
    • Under 750 N/m or Category 2 lateral loading (using the same connection, with increased post thickness)
